Madewell MP-940C Laser-Guided Screed

Product Description

The MP-940C provides unmatched versatility and simplicity with increased power and productivity! Available with a fully automated self-leveling screed head, raking/fine grade head, this powerful machine has fewer switches and an easy-access hinged console, making any job comfortable for your operator. It has a foldable elevation beam that provides a narrower profile during transport with the added benefit of providing easy entry to jobsites.

Inclusions:
 - Complete spare parts and tool kit*
- 3 Days comprehensive on-site training
- High float tyres
- Tripod/Laser/trimble receivers

Features:
- Advanced SLS (Self-Leveling System) for consistent, high-precision slab finishes
- Self-propelled ride-on design with 4-wheel hydraulic drive
- Hydraulic vibration system delivering uniform compaction
- 3.0m leveling width and quick-pass settings to optimize work rate
- 25 HP Honda GX690 engine
- Foldable elevation beam for narrow transport profile and easy jobsite access
- Compatible exclusively with Leica 3D system
- Column-block protection and high float tyres for diverse site conditions

Specifications:
- Model: MP-940C
- Weight: 1,840 lbs / 835kg
- Dimensions:  Height: 4’9”/1.5 m (transport mode) Length: 10’6”/3.2 m (transport mode)
- Engine: 25 HP/18.4 kW Honda Gx690
- Self-propelled: 4-Wheel Drive w/ Hydraulic Motors
- Fuel tank:  Gas (19L)
- Leveling width: 3.0m/ 9.84ft
- Vibrator width: 120”
- Vibration system: Hydraulic vibration
- Quick pass: 3 quick pass setting
- Trimble receivers: Column block feature
